Ezviz CS-H8(5MP)

Pan dan Tilt Wi-Fi Camera CS-H8(5MP)

Deskripsi Produk
ModelCS-H8-R100-1J5WKFL
Camera

• Shutter SpeedSelf-adaptive shutter Lens 4mm@ F1.6, Viewing angle: 46° (Vertica), 89° (Horizontal), 104° (Diagonal) 6mm@ F1.6, Viewing angle:28° (Vertica), 54° (Horizontal), 62° (Diagonal)
• PT AnglePan: 340°, Tilt: 80°Minimum Illumination 0.5 Lux @ (F1.6, AGC ON), 0 Lux with IR (Data is obtained from EZVIZ laboratories)
• Lens Mount M12 Day & Night IR-cut filter with auto-switching DNR3D DNRWDR Digital WDR Night Vision Distance Up to 30m / 98ft
• Video & Audio Max. Resolution2880 × 1620Frame RateMax:30fps; Self-Adaptive during network transmission
• Video Compression H.265 / H.264H.265
• Type Main Profile Video Bit Rate Quad HD+; Full HD; Hi-Def; Standard. Adaptive bit rate.
• Audio Bit RateSelf-Adaptive Max. Bitrate4 Mbps

Network

• Wi-Fi StandardIEEE802.11b, 802.11g, 802.11n
• Frequency Range2.4 GHz ~ 2.4835 GHz
• Channel Bandwidth Supports 20 MHz
• Security WPA-PSK / WPA2-PSK
• Transmission Rate 11b 11Mbps, 11g 54Mbps, 11n 72Mbps
• Wi-Fi Pairing AP pairing
• Protocol EZVIZ Cloud Proprietary
• Protocol Interface Protocol EZVIZ Cloud Proprietary
• Protocol Wired Network RJ45 × 1(10M / 100M Adaptive Ethernet Port)

Storage

• Local Storage Supports Micro SD card (Up to 512GB)
• Cloud StorageSupports EZVIZ CloudPlay storage (Subscription required)
• Function Smart Alarm AI Powered Human / Vehicle Detection / Waving-Hand Recognition & Control Auto Tracking Supports Customized Alert Area Supports
• Two-way Talk Supports
• General Function Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark

General

• Operating Conditions-30 °C to 50°C ( -22 °F to 122 °F ), humidity 95% or less (non-condensing)
• IP Grade Weatherproof Design
• Power Supply DC 12V / 1A
• Power Consumption MAX. 6W
• Dimensions 116 × 153.2 × 163.8 mm (4.57 × 6.03 × 6.45 inch)
• Packaging Dimensions 187 × 174 × 186.5 mm (7.36 × 6.85 × 7.34 inch)Weight
• Net Weight: 592 g (20.88 oz) With Package: 943 g (33.26 oz) For EU Standard Version

In the box
– H8 Pro 3K Camera
– Power Adapter
– Screw Kit
– Waterproof Kit
– Drilling Template
– Regulatory Information
– Quick Start Guide
