Ezviz CS-H8c(4G)

Pan & Tilt 4G Camera CS-H8c(4G)

Deskripsi Produk
ModelCS-H8c-R200-1K3KFL4GA
Camera

• Image Sensor 1/2.8″ Progressive Scan CMOS
• Shutter SpeedSelf-adaptive shutter
• Lens 4mm@ F1.6, viewing angle: 46° (Vertical), 86° (Horizontal), 102° (Diagonal) 6mm@ F1.6, viewing angle: 28° (Vertical), 52° (Horizontal), 62° (Diagonal)
• PT Angle Pan: 350°, Tilt: 80° Minimum Illumination 0.5 Lux @(F1.6, AGC ON), 0 Lux with IR (*data is obtained from EZVIZ laboratories)
• Lens Mount M12DNR3D DNRWDR Digital WDR Black & White Night 30m / 98ft

Video & Audio

• Max Resolution 2304 × 1296
• Frame RateMax: 30fps; Self-Adaptive during network transmission
• Video Compression H.265 / H.264H.265
• Type Main Profile Video Bit Rate Ultra-HD; Hi-Def; Standard. Adaptive bit rate.
• Audio Bit RateSelf-Adaptive Max. Bit rate 3 Mbps

Network

• Frequency Bands
  IN LTE-FDD?B1/B3/B5/B8
  IN LTE-TDD?B34/B38/B39/B40/B41
  EU LTE-FDD?B1/B3/B5/B7/B8/B20/B28
  LA LTE-FDD?B2/B3/B4/B5/B7/B8/B28/B66
• Wired Network RJ45 × 1 (10M / 100M Adaptive Ethernet Port)
• Functions Smart Alarm Human Motion Detection, Vehicle Detection Auto Tracking Supports Customized Alert Area
• Supports Two-way Talk
• Supports Preset Locations Supports
• General Function Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark

Storage

• Local Storage Supports microSD Card (Up to 512 GB)
• Cloud Storage Supports EZVIZ Cloud Play storage (Subscription required)

General

• Operating Conditions-30°C to 50°C ( -22 °F to 122 °F )
• Humidity 95% or less (non-condensing)
• IP Grade Weatherproof

Design

• Power Supply DC 12V/1A
• Dimensions 100 × 136 × 140mm (3.94 × 5.35 × 5.51 inch)
• Packaging Dimensions 140 × 140 × 192mm (5.51 × 5.51 × 7.56 inch)Weight
• Net Weight: 513.8 g (18.12 oz) With Package: 796.7 g (28.1 oz) For EU Standard Version

In the box
– H8c 4G Camera
– Drill Template
– Screw Kit
– Waterproof Kit
– Power Adapter
– Regulatory Information
– Quick Start Guide
